An eccentric bolt is the pivot bolt of an independent suspension arm: its off-centre cam shifts the arm to set wheel alignment. Replacement eccentric bolt for the original; have the alignment reset once the new one is torqued. Before ordering, measure the old bolt end to end (165 mm), across the shank (Ø16 mm) and along the threaded end (40 mm).

  • Ø16 × 165 mm shank with a 40 mm threaded end: measure the old bolt end to end and check the thread length before ordering
  • Dacromet finish: a rust-resisting coating for hardware that lives in the exposed underbody behind the wheel
  • Cam position sets alignment: mark the old cam angle before you pull it, then have toe and camber checked after fitting
  • 0.373 kg
